Key Features
6kW Rated Output Power – Suitable for homes, offices, and small commercial solar systems
12kVA Surge Capacity – Handles heavy startup loads easily
Built-in 100A Solar Charger – Efficient solar charging for faster battery recovery
27A Maximum PV Input – Optimized solar energy utilization
MPPT Operating Voltage 60-450V – Wide solar input range for flexible panel configurations
500V Max PV Open Circuit Voltage – Supports larger solar arrays
Dual AC Output – Dedicated output for critical and non-critical loads
Built-in WiFi Monitoring – Remote monitoring via mobile app
5-inch LCD Display – Clear and user-friendly system interface
Generator Compatible – Works with backup generators for extended power reliability
Lithium Battery Activation – Easy integration with lithium battery systems
Supports Lithium-ion & Lead-acid Batteries – Flexible battery compatibility
Pure Sine Wave Output – Safe for sensitive electronics and appliances
Fast 10ms Transfer Time – Seamless switching during power outages
| Specification | Details |
|---|---|
| Model | PV Tech 9000 |
| Rated Capacity | 6 kW |
| Surge Power | 12 kVA |
| AC Input Voltage | 208 / 220 / 230 / 240 VAC |
| Voltage Range | 90-280V (Normal Mode), 170-280V (UPS Mode) |
| Frequency | 50 / 60Hz (Auto Adaptive) |
| AC Output Voltage | 208 / 220 / 230 / 240 VAC |
| Power Factor | 1.0 |
| Waveform | Pure Sine Wave |
| Switch Time | 10ms |
| Max Efficiency | 94% @ 48VDC |
| Solar Charger Type | MPPT |
| Max PV Input | 27A / 9000W |
| MPPT Voltage Range | 60-450V |
| Max PV Open Circuit Voltage | 500V |
| Max PV Charge Current | 120A |
| Max AC Charge Current | 120A |
| Battery Voltage | 48V |
| Battery Type | Lithium-ion / Lead-acid |
| Display | LCD |
| Communication | RS485 / RS232 / USB |
| Monitoring | WiFi (Optional Internal / External) |
| Protection Level | IP21 |
| Operating Temperature | -10°C to 50°C |
| Net Weight | 8.4 kg |
| Dimensions | 410 × 334 × 110 mm |
