Name: Solis 10kW S6-EH1P(3-10)K-L-PLUS Hybrid Inverter | IP66 Single Phase Solar Inverter | 2 MPPT | 10kW Backup Support
SKU: 5706
Price: 415000 PKR
Availability: InStock

Solis 10kW S6-EH1P(3-10)K-L-PLUS Hybrid Inverter | IP66 Single Phase Solar Inverter | 2 MPPT | 10kW Backup Support

The Solis 10kW S6-EH1P(3-10)K-L-PLUS Hybrid Inverter is a powerful and reliable single-phase solar inverter designed for residential and small commercial solar systems. Built with IP66 protection, it is suitable for both indoor and outdoor installations, offering durability in harsh weather conditions.

₨ 415,000 ~~₨ 445,000~~

Key Features

10kW single-phase hybrid inverter

IP66 rated for outdoor and indoor installation

2 MPPT trackers with 4 input strings

Supports Li-ion and Lead-acid batteries (40–60V)

10kW full backup output capability

High PV capacity up to 20kW recommended array size

Wide MPPT voltage range (90–435V)

Advanced grid and battery management system

Specification	Details
Recommended Max. PV Array Size	20 kW
Max. Usable PV Input Power	16 kW
Max. Input Current	42 A / 42 A
Max. Short Circuit Current	48 A / 48 A
MPPT / Max. Input Strings	2 MPPT / 4 Strings
Max. Charge / Discharge Power	10 kW
Max. Charge / Discharge Current	210 A
Battery Type	Li-ion / Lead-acid (40 – 60 V)
Rated Output Power (Grid)	10 kW
Max. Apparent Output Power	10 kVA
Rated Grid Output Current	45.5 A / 43.5 A
Max. Input Current (Grid)	65 A
Rated Output Power (Back-up)	10 kW
Rated Output Current (Back-up)	45.5 A / 43.5 A
Rated Grid Voltage	L/N/PE, 220 V / 230 V
MPPT Voltage Range	90 – 435 V
Dimensions (W × H × D)	335 × 560 × 253 mm
