Name: GA&amp;DA GDM4-63/63-3300 63A MCCB Breaker – Reliable Molded Case Circuit Breaker for Electrical Protection
SKU: 5935
Price: 4799 PKR
Availability: InStock

GA&DA GDM4-63/63-3300 63A MCCB Breaker – Reliable Molded Case Circuit Breaker for Electrical Protection

The GA&DA GDM4-63/63-3300 MCCB is a durable and high-performance Molded Case Circuit Breaker designed to provide dependable protection for electrical circuits against overloads, short circuits, and faults. With a rated current of 63A, breaking capacity up to 35kA, and wide operating voltage up to 690V AC, it delivers reliable performance and long service life even under demanding conditions.

₨ 4,799 ~~₨ 7,899~~

Key Features

High breaking capacity up to 35kA for enhanced safety
Compact molded case design for space-saving installation
Dual voltage rating (400V / 690V AC) for flexible applications
CE certified and IEC/EN 60947-2 compliant
Reliable performance in industrial and commercial environments
Durable construction with tested operation at 40°C ambient temperature

Specification	Details
Model	GA&DA GDM4-63/63-3300
Type	MCCB (Molded Case Circuit Breaker)
Rated Voltage (Ue)	AC 400V / 690V
Rated Current (In)	63A
Frequency (f)	50 / 60Hz
Rated Short-Circuit Breaking Capacity (Icu)	35kA (at AC400V) / 10kA (at AC690V)
Rated Service Breaking Capacity (Ics)	25kA (at AC400V) / 5kA (at AC690V)
Rated Impulse Withstand Voltage (Uimp)	8kV
Rated Short-Time Withstand Current (li)	10 In
Utilization Category	Category A
Standard Compliance	IEC / EN 60947-2
Operating Temperature	40°C
Certification	CE Certified
Manufacturer	Gandian Lightning Protection Electric Co., Ltd.
